Autel MS908CV II vs MS909CV: Which is better for heavy-duty vehicle repairs

What Makes a Diagnostic Scanner Crucial for Heavy-Duty Vehicle Repairs?

With the development of the car industry, electronic control systems are widely used in heavy vehicles, and fault diagnosis has become more complex.Only with the help of professional diagnostic scanners can maintenance personnel keep up with the pace of vehicle technology development and effectively repair and maintain new vehicles.

Heavy vehicles have complex structures, including numerous key components such as engines, transmissions, and braking systems. Once a malfunction occurs, troubleshooting becomes extremely difficult. The haevy duty scanner accurately locates the root cause of the problem, which greatly improves efficiency compared to traditional manual troubleshooting.

Comprehensive comparison between MS908CV II and MS909CV

MS908CV II vs MS909CV:Brief description

MS908CV II at a Glance

  • Processor power:

The Autel MS908CV II is equipped with an 8-core processor. This has been upgraded on the quad core processor used in its previous generation product, the MS908CV scanner. The more advanced processor enables smoother operation of the Autel MS908CV II for heavy-duty vehicle fault detection without any lag or delay, while also ensuring fast processing of relevant data.

The MS908CV scanner has powerful hardware configuration.

Powerful hardware configuration of MS908CV

  • Display:

The MS908CV II has a 9.7-inch LED capacitive touch screen with a resolution of 2048 x 1536. The larger screen and clearer resolution make the operation interface and diagnostic data of MS908CV II clearer, reflecting the user-friendly design concept.

  • Vehicle coverage:

Powered by the latest advancements, the Autel MS908CV II provides full-coverage diagnostics for Class 1-9 heavy-duty vehicles, from light trucks to massive rigs.Its advanced capabilities ensure future-proof performance, keeping up with evolving industry standards and complex repair demands.

MS909CV at a Glance

  • Upgraded features compared to MS908CV II:

On the VCI device, the MS909CV scanner uses MaxiFlash VCI, which supports a wider range of protocols than the MaxiFlash Elite used by the MS908CV II, and also has faster graphics processing capabilities.

  • Unique functions:

MS909CV has unique diagnostic functions that MS908CV II does not have. MS909CV can perform intelligent diagnosis,which provides comprehensive assistance in quickly and accurately diagnosing and repairing vehicle issues by matching fault codes with original TSBs, offering DTC analysis, repair guidance, repair tips, and relevant case references.

In addition, the topology mapping, advanced driver assistance system calibration and battery analysis functions of MS909CV provide a more comprehensive detection range for heavy-duty vehicle maintenance, which helps to find vehicle faults more accurately.

MS909CV has fuction of topology mapping 2.0.

MS909CV has fuction of topology mapping 2.0

At the same time, these unique functions used by MS909CV also reflect that Autel heavy-duty vehicle diagnostic products are constantly meeting the improved maintenance and diagnostic requirements brought about by the development of vehicle technology.

MS908CV II vs MS909CV:Comparison of Diagnostic Capabilities

Basic Diagnosis

Both MS908CV II and MS909CV have OE-level full system diagnostic functions. Basic functions include ECU information, reading fault codes, clearing fault codes, reading freeze frames, display live data, and performing active tests.

However, compared with the MS908CV II, the MS909CV adds the function of topological mapping.The intuitive topological mapping function of MS909CV can display the status of each module and the number of fault diagnosis codes on the same page.

It also can show the communication structure between modules, facilitate the understanding of the wiring diagram of highway trucks, support clicking to enter the system or module with fault codes, and also view the color-coded modules by zooming.

Connectivity and Expandability

In terms of connection, both the MS909CV and the MS908CV II can be connected via WIFI, USB, Bluetooth and HDMI. However, there are also some subtle differences. For example, in terms of wifi connection, the MS909CV supports Wi-Fi x2 (802.11a /b/g/n/ac 2x2 MIMO).

Compared with the wifi of the MS908CV II, the transmission rate is increased, the coverage area is enhanced, and the anti-interference ability is upgraded.

Compared with the MS908CV II, the MS909CV supports heavy Duty Battery Test

The MS909CV supports heavy Duty Battery Test

In terms of extended functions, compared with the MS908CV II, the MS909CV supports heavy Duty Battery Test & Health Report with included MaxiBAS B200 tester with alligator clamps.In addition,the MS909CV has ADAS Calibration Software for Class 3-5 vehicles and Class 6 to 8 Vehicles with Dynamically Calibrated Systems.

ompared with the MS908CV II,the MS909CV supports ADAS software.

The MS909CV supports ADAS software

Summary Table

MS908CV II MS909CV
Price
Hardware
Screen 9.7inch 9.7inch
Battery 1500mAh 1500mAh
Processor Octa-core Octa-core
Memory 4G+128G 4G+128G
Camera 16MP & 5.0MP 16MP & 5.0MP
Conectivity Wi-Fi (802.11 a/b/g/n/ac)
USB 2.0
Bluetooth v5.0 + EDR
SD card (support up to 64 GB)
HDMI
Wi-Fi x 2 (802.11 a/b/g/n/ac 2x2 MIMO)
BT V5.0
GPS
USB 2.0 (two USB host type A, one USB mini
device)
HDMI 2.0
SD card (supports up to 256 GB)
VCI MaxiFlash elite MaxiFlash VCI
Software
Operating System Android 10.0 Android 10.0
Software Updates 1 YEAR FREE 1 YEAR FREE
Automatic Detection Auto-Vin / Auto-Scan / ScanVin Auto-Vin / Auto-Scan / ScanVin
Vehicle Coverage Class 3 - Class 9 Class 3 - Class 9
OBDII Test Modes - All 10 test modes
Service Resets 25 Service Features 25 Service Features
Diesel PM Class 1-9 Class 1-9
System Diagnostics Access All Modules
In All Systems on Select Vehicles
Access All Modules
In All Systems on Select Vehicles
Component Activations Bi-directional Controls Bi-directional Controls
Enhanced Functions Advanced Coding + Adaptations Advanced Coding + Adaptations
ADAS Calibration - Access Static Calibration Class 3-5*
Class 6-8 Dynamic Calibration
Battery Analysis - Support heavy Duty Battery Test & Health Report
(MaxiBAS B200 tester )

Selection Guide:Autel MS908CV II vs MS909CV

  • Choose MS908CV II:

For small repair shops or individual repair practitioners with limited funds and daily maintenance work mainly focused on routine troubleshooting and basic maintenance services, Autel MS908CV II is undoubtedly a cost-effective choice.

It can not only meet the core needs of daily basic maintenance scenarios, but also effectively control operating expenses at a relatively affordable price. At the same time, with its stable performance, it ensures the smooth progress of basic maintenance work.

  • Choose MS909CV:

For large repair shops or professional heavy vehicle repair institutions that pursue an efficient maintenance process and are committed to providing professional-level services, the Autel MS909CV is undoubtedly the ideal choice.

With its powerful performance configuration, such as topology mapping function, over 53 rich service functions, and outstanding ECU programming capabilities, it can meet all kinds of high-end maintenance demands.

These advantages enable the maintenance work to be advanced efficiently and help maintenance institutions achieve sustainable development.

Conclusion

The Autel MS908CV II and MS909CV have similarities in hardware configuration, both based on the Android 10.0 operating system, equipped with an eight core processor and a 9.7-inch large screen truck scanner.

But in terms of diagnostic function, MS909CV has a slight advantage with its unique features of topology mapping, ADAS calibration, and battery analysis.

Both Autel MS908CV II and MS909CV have their own advantages and disadvantages, and either can meet the basic testing needs of heavy-duty vehicles. If you want a more professional and comprehensive function, MS909CV will be better.
