Autel MaxiSYS MS909CV Reviews 2021

Autel MaxiSYS MS909CV is compatible with more than 80 models of light-, medium- and heavy-duty vehicles. The 9.7-in. wireless tablet performs vehicle diagnostics, including the ability to read/erase codes (active and inactive codes), view and graph live data and perform active tests. The tablet includes a Bluetooth-enabled vehicle communication interface (VCI)/J2534 pass-thru programmer, the MaxiBAS B200 battery, starting and charging system tester and alligator clamps, and multimeter and amp clamp.

The tablet includes ADAS calibration software for Class 3 to 5 vehicles and Class 6 to 8 vehicles with dynamically calibrated systems. Autel MaxiSys MS909CV 3-1 Heavy Duty Repair Programmer Device features the Android 7 operating system, enabling contextual code definitions and access to repair information, technical service bulletins and OE service campaigns. The MS909CV includes a one-year limited warranty and a year of free software updates.

  • Upgraded Octa-Core processor and 128GB storage and Android 7.0 Operating System with 9.7” Touchscreen and the whole-new MaxiFlash VCI to deliver smooth operation
  • Intelligent Diagnostics with Module Topology on Select Vehicles and Enhanced AutoSCAN / VINScan and DTC Analysis / Repair Guided Assist
  • ADAS Calibration with new Class 6-8 Dynamic Calibration, Supporting Class 3-5 Complete ADAS Coverage. The Class 6-8 Static Calibration (coming soon)
  • Support heavy Duty Battery Test & Health Report
Autel Maxisys MS909CV Heavy Truck Scanner
Autel Maxisys MS909CV Heavy Duty Truck Scanner
4.8
The Autel MaxiSys MS909CV Heavy Duty Bi-Directional Diagnostic Scanner provides the full functionality and online repair information you need when diagnosing vehicles,identifying faults and researching repair issues.

MS909CV Specifications

Operating   System Android 7.0
Processor Samsung   Exynos 8895V octa-core Processor (2.3GHz Quad-core Mongoose + 1.7GHz   Quad-core A53)
Memory 4GB   RAM & 128GB On-board Memory
Display 9.7-inch   TFT-LCD with 1536 x 2048 resolution & capacitive touch screen
Connectivity WiFix2   (802.11 a/b/g/n/ac 2x2 MIMO)
BT v.2.1 + EDR
GPS
USB 2.0 (TWO USB HOST Type A, ONE USB mini   device)
HDMI 2.0
SD Card (Support up to 256GB)
Camera Rear:   16 Megapixel, Autofocus with Flashlight
Front: 5.0 Megapixel
Sensors Gravity   Accelerometer, Ambient Light Sensor (ALS)
Audio Input/Output Microphone
Dual Speakers
3-Band 3.5 mm stereo/standard headset jac
Power and Battery 15000mAH   3.8V lithium-polymer battery
Charging via 12V AC/DC power supply with the   temperature between 0°C and 45°C
Input Voltage 12V/3A   Adapter
Operating Temperature 0   to 50°C (32 to 122°F)
Storage Temperature -20   to 60°C (-4 to 140°F)
Dimensions(W x H x D) 304.4   mm (11.98") x 227.8 mm (8.97") x 42.5 mm (1.67")
Weight 1.66kg   (3.66 lb.)
Protocols DoIP,   PLC J2497, ISO-15765, SAE-J1939, ISO-14229 UDS, SAE-J2411 Single Wire   Can(GMLAN), ISO-11898-2, ISO-11898-3, SAE-J2819 (TP20), TP16, ISO-9141,   ISO-14230, SAE-J2610 (Chrysler SCI), UART Echo Byte, SAE-J2809 (Honda   Diag-H), SAE-J2740 (GM ALDL), SAE-J1567 (CCD BUS), Ford UBP, Nissan DDL UART   with Clock, BMW DS2, BMW DS1, SAE J2819 (VAG KW81), KW82, SAE J1708,   SAE-J1850 PWM (Ford SCP), SAE-J1850 VPW (GM Class2)
