Autel MS906 Pro vs Launch X431 Pro3S+ V5: 2026 Scanner Comparison

Both Autel and Launch are excellent car diagnostic tools, and they are often compared when people are shopping for one. Have you found the diagnostic tool that meets your needs in 2026?

Today, we’ll provide a comprehensive comparison of the Autel MS906 Pro and the Launch X431 Pro3S+ V5 to help you better understand their features and performance, so you can make a more informed purchasing decision.

Brief Overview

Overview of the Autel MS906 Pro

The Autel MS906 Pro is a relatively new, professional vehicle diagnostic scan tool that covers the entire vehicle system. It not only supports over 3,000 active test functions but also offers advanced features such as ECU coding, remote expert assistance, and ADAS extensions, providing users with a comprehensive vehicle diagnostic solution.

Overview of the Launch X431 Pro3S+ V5

The LAUNCH X431 PRO3S+ V5.0 is an advanced 10.1-inch professional scanner featuring an upgraded Android 10 octa-core tablet with dual-band Wi-Fi and a 15-hour battery.

Supporting over 200 car brands (including 24V trucks via optional modules), it delivers full bi-directional control, advanced ECU coding, 55+ reset services, and free VAG guided functions. With 2 years of free updates and full all-system diagnostics, it provides efficient, dealer-level performance for both technicians and DIYers.

Autel MS906 Pro vs Launch X431 Pro3S+ V5: Comparison Chart

Basic Info	Item	Autel MS906 Pro	Launch X431 Pro3S+ V5
	Price	$1,059	$985
Hardware	Processor	Octa-core processor (2.2 GHz + 1.8 GHz)	4-core processor
	Battery	11600 mAh	6300 mAh
	Screen Size	8.0-inch	10.1-inch
	Screen Resolution	1920 x 1200	1280*800
	Camera	Rear: 16 megapixel, autofocus with flashlight Front: 16 megapixel	Rear: 8 megapixel
	VCI	MaxiVCI V200	DBScar VII
	Memory	4 GB RAM & 128 GB on-board memory	4 GB RAM & 64 GB
	Connectivity	Wi-Fi (802.11 b/g/n) USB: 2.0 Mini USB 2.0 Bluetooth V2.1+EDR, Class1 HDMI SD Card (support up to 32 GB)	Wi-Fi Bluetooth
	Weight	0.92 kg (2.03 lb.)	/
Software	Operating System	Android 10	Android 10
	Basic Functions (Read Codes, Clear Codes, Data Stream)	✔	✔
	Service	31+	30+
	Special Functions	✔	✔
	Bi-Directional Control(Active Test)	✔	✔
	Advanced ECU Coding	BMW, Mini, Audi, Porsche, VW, VW_Brazil	BMW, VW, Audi, Skoda, SEAT, Porsche, etc.
	Unlock Hidden	✔	✔
	Topology Mapping	✘	✔
	Language	Only English	/
	Autel Cloud Service	✔	/
	DoIP/CAN FD	✔	An adapter is required
	Wifi Print	✔	✘
Extended Function	Battery Test (requires BT506)	✔	Must be purchased separately.
	Endoscope Function (requires MV105/MV108)	✔	Must be purchased separately.
	ADAS Expansion	✔	Must be purchased separately.
	Remote Expert	✔	/

Autel MS906 Pro vs Launch X431 Pro3S+ V5: Key Differences

Key Differences Table

Hardware Configuration

1. Processor Differences

• Autel MS906 Pro: 8-CORE
• Launch X431 Pro3S+ V5: 4-CORE

There is a significant difference in processors between these two vehicle diagnostic scan tools: the Autel scanner’s octa-core processor—compared to the Launch scanner’s quad-core CPU—delivers faster data processing, superior multitasking capabilities, and more sustained system fluidity, helping to noticeably boost your work efficiency.

2. Memory Differences

• Autel MS906 Pro: 4 GB RAM & 128 GB
• Launch X431 Pro3S+ V5: 4 GB RAM & 64 GB

These two vehicle diagnostic scan tools have the same amount of RAM, but their storage capacity differs. The Autel MS906 Pro offers more storage, allowing you to download diagnostic packages for multiple automotive brands and save more diagnostic reports. For auto repair shops, this is a powerful tool for expanding their business and enhancing customer satisfaction.

Autel MS906 Pro Hardware Overview

3.Battery Capacity

• Autel MS906 Pro: 11600 mAh
• Launch X431 Pro3S+ V5: 6300 mAh

The Autel MS906 Pro has a larger battery capacity, and battery capacity is a key factor in determining battery life. Battery life is crucial for complex diagnostic tasks and extended periods of continuous operation; after all, no customer is going to wait for your diagnostic scanner to finish charging before coming in.

4. Screen Differences

• Autel MS906 Pro: 8-inch, 1920*1200
• Launch X431 Pro3S+ 5V: 10.1-inch, 1280*800

The Autel MS906 Pro scanner has a relatively small screen, though it boasts high resolution; the Launch scanner is the exact opposite. A larger screen allows for the display of more detailed diagnostic data, while higher resolution ensures greater clarity—both of which significantly enhance the user experience.

Software Capabilities

In terms of software features, both of these vehicle diagnostic scan tools support ECU programming and bidirectional control, but there are some differences between them. For example, the Autel MS906 Pro does not include a topology view feature, but compared to the Launch scanner, it supports a wider range of vehicle models and receives updates more quickly.

Autel MS906 Pro Remote Expert Functions

Extended Functionality

Compared to the Launch X431 Pro3S+ 5V, the Autel MS906 Pro supports DoIP and CAN FD communication protocols, enabling it to work with a wider range of vehicle models. It also features a remote expert function that can provide assistance when you encounter difficulties. In addition, both scanners support extended features such as battery diagnostics and endoscope connectivity.

Which One Should You Buy?

• Choose Autel MS906 PRO:If you prioritize hardware specifications, want a diagnostic tool built for long-term use, or wish to expand your service coverage, this Autel scan tool is a great choice.
• Choose Launch X431 Pro3S+ V5: If you are looking for an affordable scanner with topology capabilities and don't have high demands regarding hardware specifications, you might consider this car diagnostic tool.

Conclusion

Both the Autel MS906 Pro and the Launch X431 Pro3S+ V5 are outstanding car diagnostic tools in the thousand-dollar price range. In addition to supporting basic diagnostic functions, both offer advanced capabilities such as ECU coding, bi-directional control, unlocking hidden features, and VAG Guided functions.

The primary differences between them lie in their hardware specifications and vehicle coverage; therefore, either scanner will effectively meet your diagnostic needs.
