Autel MaxiSys MS919 Automotive Diagnostic Tool 2021 Newset Model

Autel MaxiSys MS919 is the 2021 newest and advanced automotive diagnostic tool which combines diagnostics, service, extensive live data, channel coding, and ECU reflashing.

Autel MaxiSys MS919➡Maximize your Intelligence!

Autel MaxiSys MS919 features a 9.7-inch touchscreen tablet with Android 7.0 OS powered by an Octa-core processor (2.3GHz Quad + 1.7GHz Quad), substantial 128GB built-in memory to provide diagnostic guidance and test components to confirm repairs.

The new MaxiFlash VCMI, functions as a 4-channel oscilloscope, waveform generator, multimeter, and CAN BUS tester.MS919 software provides a large library of preset guided tests and extensive waveform library, to ensure techs get the best use of Oscilloscope. The MS919 software outperforms competitors by offering DTC and sensor specific test options to help test more accurately, as well as providing probe and component location diagrams so technicians test while connected correctly.

MS919Intelligent Diagnostics function

OE Technical service bulletin (TSB): Official statement to eliminate unnecessary inspection process
Repair Assist: Prioritize DTCs, and step-by-step guide to fix fault
DTC Analysis: Define DTC, causes and inspection methods and DTCs Rank by Priority
Repair Guidance: Repair process in videos and photos for most intuitive instruction
Component Measurement: In-depth inspection of component with oscilloscope and other measurement tools.
NOTE: Intelligent Diagnostics supported makes: BMW, GM, JLR, Ford, Chrysler, FAC, Porsche, VW, Audi etc. Please be noted that Intelligent Diagnostics is not universal to all the above vehicle brand models, please send your VIN to us before you place order.

Autel Maxisys MS919 Specifications

Operating System: Android 7.0
Processor: Samsung Exynos8895V octa-core Processor (2.3GHz Quad-core Mongoose + 1.7GHz Quad-core A53)
Memory: 4GB RAM & 128GB On-board Memory
Display: 9.7 inch TFT-LCD with 1536 x 2048 resolution & capacitive touchscreen
Connectivity: Wi-Fix2 (802.11 a/b/g/n/ac 2x2 MIMO); BT v.2.1 + EDR; GPS; USB 2.0 (TWO USB HOST Type A, ONE USB mini device); HDMI 2.0; SD Card (Support up to 256GB)
Camera (rear): Rear: 16 Megapixel, Autofocus with Flashlight, Front: 5.0 Megapixel
Sensors; Gravity Accelerometer, Ambient Light Sensor (ALS)
Audio Input/Output: • Microphone • Dual Speakers • 3-Band 3.5 mm stereo/standard headset jack
Power and Battery: 15000mAh 3.8V lithium-polymer battery
Charging via 12V AC/DC power supply with the temperature between 0°C and 45°C
Input Voltage: 12V/3A Adapter
Operating Temp.: 0 to 50°C (32 to 122°F)
Storage Temp.: -20 to 60°C (-4 to 140°F)
Dimensions (W x H x D): 304.4 mm (11.98") x 227.8 mm (8.97") x 42.5 mm (1.67")
Weight 1.66kg (3.66lb.)
Protocols DoIP, PLC J2497, ISO-15765, SAE-J1939, ISO-14229 UDS, SAE-J2411 Single Wire Can(GMLAN), ISO-11897-2, ISO-11897-3, SAE-J2819 (TP20), TP16, ISO-9141, ISO-14230, SAE-J2610 (Chysler SCI), UART Echo Byte, SAE-J2809 (Honda Diag-H), SAE-J2740 (GM ALDL), SAE-J1567 (CCD BUS), Ford UBP, Nissan DDL UART with Clock, BMW DS2, BMW DS1, SAE J2819 (VAG KW81), KW82, SAE J1708, SAE-J1850 PWM (Ford SCP), SAE-J1850 VPW (GM Class2)

Equivalent as MaxiSys Ultra, but Cost Less! Both released in 2021, Autel MS919 Scanner and MS Ultra share almost SAME software features: Intelligent Diagnostics, Module Topology Mapping, 5 in 1 VCMI, active test, ECU Programming for BWM &BENZ, ECU Coding and adaptation, same 26 service functions. Only a bit difference in hardware, but hundred of bucks less, which makes MS919 more competitive.

Top hardware configuration with smartest diagnostics features on the market, it is your best choice for winning more business and improving business competence on vehicle after-market!

source: https://www.obdprice.com/blogs/news/2021-newset-model-autel-maxisys-ms919
