When it comes to diagnostic testing on a vehicle, you could use a lot of options to help you in the endeavor, but the Autel TS608 is a no brainer. This OBD2 diagnostic and tire pressure monitoring system (TPMS) tool is one of the first ones of its kind on the market today.
In this detailed review, you will gain a greater understanding of how the Autel MaxiTPMS TS608 can work for you and your needs and how it compares and contrasts to other choices.
| Operating System: | Android™ 4.4.2, KitKat |
| Processor: | Cortex-A9 processor (1.6 GHz) |
| Memory: | 1GB RAM DDR3 & 32GB ROM |
| Display: | 7-inch LCD capacitive touchscreen with 1024x600 resolution |
| Connectivity: | Mini USB 2.0; USB2.0; Wi-Fi; HDMI Type A; Micro SD card slot(supports up to 32GB) |
| Sensors; | Light sensor for brightness auto adjust |
| Audio Input/Output: | Input: N/A,Output: Beep |
| Power and Battery: | 3.7 V/5000 mAh lithium-polymer battery Charges via 5 VDC power supply |
| Tested Battery Life: | Around 7 hours of continuous use |
| Battery Charging Input : | 5V/1.5A |
| Power Consumption: | 600 mA (LCD on with default brightness, Wi-Fi on) @3.7 V |
| Operating Temp.: | -10to60°C(14to140°F) |
| Storage Temp.: | -20to70°C(-4to158°F) |
| Operating Humidity: | 5%-95%non-condensing |
| Dimensions (W x H x D): | 270.8 mm (10.0”) x 176.0 mm (6.9”) x 36.0 mm (1.4”) |
| Net Weight | 885 g (2.31 lb.) |
| Protocols | ISO9141-2, ISO14230-2,ISO15765, K/L-Line, Flashing Code,SAE-J1850 VPW, SAE-J1850PWM,ISO11898 (Highspeed, Middlespeed, Lowspeed and Singlewire CAN, fault-tolerant CAN),SAE J2610, GM UART,UART Echo Byte Protocol,Honda Diag-H Protocol, TP2.0, TP1.6 |
PROS
CONS
Q-1: Is the Autel TPMS TS608 compatible with foreign vehicles?
• This question arises because it works well with American made cars, but many are unsure if foreign vehicles work with the TS608. It also is a great tool when working with Ferrari, Porsche, BMW, Mercedes, and many other brands.
Q-2: Does the kit come standard with sensors for the tire pressure?
• Unfortunately, for the price you pay, the sensors for tire pressure are sold separately with the device you buy. However, going through the Autel site makes it relatively easy to purchase any add-ons you want with your device.
Q-3: What is the biggest micro SD card I can add to the TS608?
• Because this device doubles as a tablet or laptop, you can add an SD card to save data to. The biggest card that works on this device is 16 GB. Most use anywhere from 4 to 8 GB.
Q-4: Are there other language options for this device?
• Autel can support other languages on the TS608, like Spanish. However, there are a few steps you have to take to make this happen. First, register the device. Next, call Autel customer service. Then, they can change the language for you.
Q-5: After the warranty is up, how much does it cost to update the Autel TS608?
• When the warranty is complete, it costs $350 to update the software fully through Autel.
Q-6: Can diesel vehicles be scanned with the Autel TPMS TS608?
• The coverage extends to trucks upwards of 8600, including medium-duty trucks. However, some tractor-trailers, like the MS908CV or MS906CV, are compatible with this device as well.
Q-7: How do I install new updates to this device?
• Because this product is wirelessly capable, you can update using your wireless connection.
Autel TS608 TPMS tool is one of the most advanced TPMS tools that you will come across on the market. Not only is it easy to use with a backlit screen, but it is also fast and very powerful. Even though this unit can be used to diagnose basic TPMS functions, it is suitable for advanced functions due to its high initial price. It can also perform OBD2 functions and has wireless Bluetooth for convenient use inside the garage.
TPMS is the abbreviation of Tire Pressure Monitoring System. A Tire Pressure Monitoring System (TPMS) is a critical vehicle safety feature that continuously tracks air pressure levels in pneumatic tires.
The Autel MaxiSys Ultra S2 takes automotive diagnostic accuracy to the next level with its higher level of performance advantages, advanced VCMI2 devices and enhanced oscilloscopes, upgraded Topology Map 3.0, and AI-assisted diagnosis.
From a simple handheld OBD code reader, to the ability to perform basic diagnosis of four systems, and then to full system diagnostic functions, the Autel vehicle diagnostic scanning tool is constantly developing towards more comprehensive functions and wider coverage.
