Autel MP808BT Pro vs MS906 Pro: Best Autel Scanner in 2026

Autel offers a wide variety of scanners, which can be a challenge for consumers who have difficulty making choices. However, things become a little simpler if you have specific diagnostic needs and a specific budget. Today, we'll compare two best-selling Autel scanners to help you make your selection.

Both the Autel MP808BT Pro and Autel MS906 Pro are excellent automotive scanning tools. What are the differences between them in terms of hardware configuration, software features, and user experience? Which one will be the best Autel scanner in 2026? Let's take a look!

Brief Introduction

What is the Autel MP808BT Pro?

The Autel MaxiPRO MP808BT Pro is an advanced wireless automotive diagnostic scanner that provides professional diagnostic services to customers.

It features a powerful Samsung hexa-core processor, a 7.0-inch display, and supports wireless communication up to 10 meters (33 feet). Based on the Android 11.0 operating system, it boasts best-in-class OE diagnostic capabilities, enabling efficient and comprehensive vehicle diagnostics and analysis.

What is the Autel MS906 Pro?

The Autel MaxiSYS MS906 Pro is a powerful 8-inch diagnostic tablet. It features an octa-core processor, Android 10.0 operating system, and 128 GB of memory.

The Autel MS906 Pro diagnostic scanner can perform comprehensive vehicle diagnostics, including full system scans, reading/clearing fault codes, viewing freeze frames and real-time data, and two-way control (including active testing, coding, and fitting).

Autel MS906 Pro Features Overview

Autel MP808BT Pro vs MS906 Pro: Comparison Chart

Basic Info	Item	Autel MP808BT Pro	Autel MS906 Pro
	Price	$589.00	$1,059.00
Hardware Configuration	Processor	Cortex-A55 quad-core processor (1.8GHz)	Octa-core processor (2.2 GHz + 1.8 GHz)
	Screen Size	7 inch	8.0-inch
	Screen Resolution	1024 x 600	1920 x 1200
	Memory	4GB RAM & 64GB ROM	4 GB RAM & 128 GB
	Baterry	5000 mAh	11,600 mAh
	VCI	MaxiVCI Mini	MaxiVCI V200
	Connectivity	Mini USB 2.0 USB 2.0 Wi-Fi Bluetooth HDMI Type A Micro SD card (supports up to 64 GB)	Wi-Fi (802.11 b/g/n) USB: 2.0 Mini USB 2.0 Bluetooth V2.1+EDR, Class1 HDMI SD Card (support up to 32 GB)
	Weight	885 g (2.31 lbs.)	0.92 kg (2.03 lb.)
Software	Operating System	Android 11.0	Android 10
	Diagnostic Syestem	All Systems
	Auto VIN	✔	✔
	Bi-directional Control	✔	✔
	ECU Offline Coding	✔	✔
	ECU Online Coding	✔	✔
	Reflash Hidden Functions	✔	✔
	Service Functions	37+	37+
	Languages	Multilingual	Only English
	Softwave Update	2 Years Free	1 Year Free
Other Functions	FCA Auto Auth	✔	✔
	CAN FD/DoIP	✘	✔
	Remote Desk	✔	✔
	Wi-Fi Print	✔	✔
	Remote Expert	✘	✔
	Report Management	✔	✔
	IP Restriction	✘	✘
Extended Functions	Baterry Test	✔(BT506)	✔(BT506)
	Endoscope Functions	✔(MV105S/MV108S)	✔(MV105S/MV108S)
	ADAS Activation	✘	✔

Autel MP808BT Pro vs MS906 Pro: Key Differences

Hardware Comparison

1. Processor

The Autel MP808BT Pro features a quad-core processor, while the Autel MS906 Pro boasts an octa-core processor. The octa-core processor means the Autel MS906 Pro offers faster performance, can handle more complex tasks, and ensures smooth operation even after extended use.

2. Screen and Memory

The Autel MS906 Pro boasts a larger screen size, resolution, and more memory than the MP808BT Pro. A larger, more easily accessible screen means more complete data display and clearer split-screen data presentation.

Simultaneously, the increased memory allows for the downloading of more vehicle brand data and the retention of more diagnostic reports, significantly enhancing the user experience.

3. Baterry

The Autel MS906 Pro has a much larger battery capacity than the MP808BT Pro, which means it has a longer battery life and is more suitable for carrying around for work. It can also guarantee long battery life when handling complex diagnostic tasks.

Autel MS906 Pro Hardware Configuration

Software Differences

1. Operating System

The Autel MP808BT Pro runs on Android 11.0, ensuring enhanced security and faster processing speeds.

2. Languages

The Autel MP808BT Pro supports multiple languages, but the MS906 Pro only supports English. This means that if you are not in a Europe or America where English is the primary language, using the Autel MS906 Pro will be less convenient.

3. Free Software Update Duration

The Autel MP808BT Pro offers two years of free software updates, with annual software upgrades costing $259. The MS906 Pro, on the other hand, only offers one year of free software upgrades, with annual upgrades costing $269. The MP808BT Pro is also cheaper, making it suitable for DIY enthusiasts with limited budgets who intend to use it long-term.

Other Functions Differences

1. CAN FD/DoIP Protocol

The Autel MS906 Pro supports CAN FD and DoIP communication protocols. It offers faster transmission speeds, supports higher data rates, and enables large-volume diagnostics and remote upgrades, covering more modern vehicle models.

2. Remote Expert

The Autel MS906 Pro supports a remote expert function, which allows for the diagnosis and resolution of complex issues from a distance, providing you with professional assistance. This is extremely convenient for DIY car owners.

Autel MS906 Pro Supports Remote Expert

Extended Functions Differences

ADAS Activation

The Autel MS906 Pro supports ADAS activation, which enables ADAS system calibration, including adaptive cruise control, night vision system, and lane departure warning, helping drivers achieve safer, more alert, and more precise driving, ensuring driving safety, and adapting to the advanced driving functions of the new era.

Which One Should You Choose?

• Choose the MP808BT PRO: if you’re a mobile tech, DIYer, or small shop owner seeking professional diagnostics and ECU coding at a budget-friendly price. It covers all essential functions and delivers reliable performance without overspending.
• Choose the MS906 PRO:if you run a busy workshop or want to future-proof your tools. With stronger hardware, broader functionality, and superior expansion capabilities, it’s built to handle more vehicles, more protocols, and more demanding workflows.

Conlcusion

The best Autel scanner is the one that best suits your needs. Both of these Autel scanners are excellent, and whether you're a DIY car owner, a repair shop, or a professional mechanic, neither will disappoint you.
