P0113 Code: Fast Diagnosis & Fix with Autel Scan Tools

Modern vehicles rely on a network of sensors to manage everything from radiator pressure to CO2 emissions. When the Check Engine Light (CEL) hits your dashboard, it’s a major headache. However, if you have a professional diagnostic setup—specifically an Autel scan tool like a MaxiCOM or MaxiCheck—you can pinpoint the culprit in seconds.

If your scanner pulls a P0113 code, here is exactly what you need to know and how to fix it.

What is the P0113 Fault Code?

The P0113 code stands for Intake Air Temperature (IAT) Sensor 1 Circuit High Input.

The PCM (Powertrain Control Module) acts as the vehicle's brain. It sends a 5-volt reference signal to the IAT sensor (a thermistor). As air temperature changes, the sensor's resistance changes:

• Cold air = Higher resistance = Higher voltage.
• Warm air = Lower resistance = Lower voltage.

A P0113 triggers when the PCM detects a constant high-voltage signal (typically 5V), suggesting an "open circuit." Essentially, the computer thinks the incoming air is impossibly cold (often reading -40°C), or the circuit is physically broken.

Essential Tools for the Job

To move beyond just reading the code, you’ll need a proper diagnostic kit:

• Autel Scan Tool: (e.g., Autel MK808Z or MS906 Pro) to view real-time "Live Data" streams.
• Digital Multimeter: To test wiring continuity, voltage, and ground.
• Infrared Thermometer: To compare actual engine bay temperatures with sensor readings.
• Flashlight: To inspect the intake boot and connectors for physical damage.

Use Multimeter Test Car Wiring

P0113 Code Common Causes & Symptoms

The Causes:

• Faulty IAT Sensor: Internal failure of the sensor is the most common culprit.
• Dirty Air Filter: While less common, a severely clogged filter can cause temperature irregularities.
• Damaged Wiring: Corroded connectors, backed-out pins, or broken "open" wires.
• Integrated MAF Sensor issues: In many modern cars, the IAT is built into the Mass Air Flow (MAF) sensor. If one fails, the whole unit often needs replacement.
• PCM Failure: Rare, but a glitch in the PCM's internal 5V circuit can trigger this.

The Symptoms:

• Illuminated Check Engine Light.
• Poor cold starting or engine hesitation.
• Lean fuel conditions leading to high emissions.
• Significant drop in fuel economy.
• Poor acceleration due to incorrect air-fuel mapping.

Check engine light as a symptom of P0113 code

How to Diagnose Code P0113 with an Autel Scan Tool

Follow these steps to accurately identify the root cause of the P0113 code using an Autel scan tool:

1. Read the Code and Check Freeze Frame Data

Start by connecting your Autel scan tool to the vehicle’s OBD-II port:

• Retrieve the P0113 code
• Check freeze frame data to see when the fault occurred
• Note intake air temperature readings at the time of the error

This helps you understand whether the issue is constant or intermittent.

2. Check Live Data from the IAT Sensor

Use your Autel scan tool to access real-time data:

• Monitor Intake Air Temperature (IAT) readings
• Compare with ambient temperature before engine start

Result:

• Unrealistic readings (e.g., -40°F or extremely high) → Sensor or circuit issue
• Normal readings → Proceed to further checks

IAT Sensor Live Data on the Autel Scanner

3. Compare IAT and Coolant Temperature

Start the engine and let it reach operating temperature. Then:

• Use your Autel scan tool to view both IAT and coolant temperature data

Result:

• IAT significantly lower than coolant temp → Normal
• IAT equal to or higher than coolant temp → Possible fault

4. Inspect Wiring and Connections

Even with scan data, a physical inspection is essential:

• Check for damaged wires, corrosion, or loose connectors
• Use a multimeter to verify proper voltage and continuity

5. Verify Sensor Response

With the Autel scan tool, observe how the IAT sensor responds:

• Slightly warm or cool the sensor (if accessible)
• Watch for real-time changes in temperature readings

No change = faulty sensor

6. Rule Out PCM Issues

If all readings and wiring check out:

• Use advanced functions on your Autel scan tool to check for additional codes
• Evaluate whether the PCM may be malfunctioning (rare case)

Check and troubleshoot PCM faults

Possible Solutions

Depending on the cause, solutions include:

• Clean or Replace Air Filter: Ensure the system can breathe.
• Repair Wiring: Fix any corrosion in the connector pins.
• Replace IAT/MAF Sensor: Often the quickest fix if the wiring tests okay.
• PCM Reflash: Sometimes a software glitch requires a "re-learn" or update.

Why Use an Autel Scan Tool?

A professional-grade Autel scan tool makes diagnosing P0113 much easier by providing:

• Accurate live sensor data
• Fast fault code identification
• Bi-directional control (on advanced models)
• Wide vehicle compatibility

Whether you’re a DIY car owner or a professional technician, Autel scanners help you pinpoint issues quickly and avoid unnecessary parts replacement.

Need Help?

If your diagnosis points to a faulty PCM or you’re unsure about the next steps, it’s best to consult a professional technician or reach out to a trusted automotive electronics specialist.

With the right tools and a systematic approach, fixing the P0113 code can be straightforward—and Autel scanners will make the process even smoother.
